Crafting a Self Bow and Arrows from Raw Wood
Build a self bow and matched arrows from raw wood. A properly tillered bow launches arrows effectively at 15-25 meters. Links to cordage and flint knapping blueprints.
Erfahren
2-3 days (multiple sessions)
Anweisungen
1
1
Select Stave
Select Stave
Straight hardwood: yew, ash, elm, or hickory. 150-170cm (ground to chin). Must be dry. The back (target side) = one continuous growth ring, never cut across grain. Avoid: pine, spruce (too soft).
Materialien für diesen Schritt:
Hardwood stave (150-170cm)1 Stück
Pine pitch glue1 Stab2
2
Shape & Nock
Shape & Nock
Mark 10cm handle at center. Taper limbs from handle to tips. D-shaped cross-section: flat back, rounded belly. Cut shallow string nocks at each tip.
Design
Cross-section diagram of bow stave showing flat back, rounded belly, taper profile
3
3
Tiller
Tiller
String loosely, pull a few cm. Both limbs must bend evenly. Shave belly where stiff — tiny amounts only. Gradually increase draw. Target: 15-25kg draw weight.
4
4
Bowstring
Bowstring
Reverse-wrap cord from strong plant fibers (see cordage blueprint). Wax with beeswax. 15cm shorter than bow for proper tension.
Materialien für diesen Schritt:
Strong cordage2 Meter5
5
Arrow Shafts
Arrow Shafts
Straight shoots (dogwood, willow), 70-80cm, 8-10mm diameter. Peel, dry, straighten over coals. Cut nock at one end.
Materialien für diesen Schritt:
Arrow shoots6 Stück6
6
Fletch & Point
Fletch & Point
3 split feathers per arrow, 10-12cm long, bound with sinew and pine pitch. Points: knapped flint, hardwood, or fire-hardened tips. Balance point 10-15% forward of center.
Materialien für diesen Schritt:
Hardwood stave (150-170cm)1 StückArrow shoots6 Stück
Feathers6 feathersPine pitch glue1 StabBenötigte Werkzeuge:
FireMaterialien
5- 1 StückPlatzhalter
- 6 StückPlatzhalter
- 2 MeterPlatzhalter
- 1 StabPlatzhalter
