Collecting Bog Iron from Marshland — Extracting Iron Ore from Wetlands

Before mining existed, early ironworkers found their ore lying in bogs. Dissolved iron in groundwater precipitates as limonite (bog iron ore) when it meets oxygen in marshes and stream beds. The distinctive orange-brown nodules were collected, dried, roasted to drive off moisture and organic matter, then crushed for smelting. Bog iron was the primary iron source for Iron Age Scandinavians, Celts, and many other cultures. This blueprint covers how to identify iron-rich wetlands, extract the ore, and process it ready for a bloomery furnace.

Intermédiaire
4-6 hours

Instructions

1

Identify Iron-Rich Marsh

Locate a marshy area where slow-moving groundwater drains through iron-rich soil — look for permanent wetlands with rusty water

2

Spot Surface Signs

Look for orange-brown staining on stones, roots, and mud at the water's edge

3

Check for Iron Film

Check for thin iridescent films on standing water — this rainbow sheen indicates dissolved iron oxidising at the surface

Step 3 - Image 1
4

Probe the Bed

Push a wooden pole into the marsh bed to test for a firm layer of ochre-coloured sediment 30-50 cm below the surface

Outils nécessaires :

Hardwood Stave (150-170cm)Hardwood Stave (150-170cm)
5

Dig into Ore Layer

Dig into the iron-rich layer with a shovel or digging stick, scooping out dark rust-coloured mud

Outils nécessaires :

ShovelShovel
6

Extract Ore Nodules

Pull out lumps of dark, rust-coloured bog ore — limonite nodules range from pebble-sized to fist-sized

Outils nécessaires :

ShovelShovel
7

Rinse in Water

Rinse each lump in clean running water to wash away mud, roots, and organic debris

Matériaux pour cette étape :

WaterWater1 bucket
8

Sort by Density

Sort the ore — keep dense, heavy pieces that ring when struck; discard light, crumbly, or porous ones

Outils nécessaires :

HammerstoneHammerstone
9

Break Large Lumps

Break larger lumps into fist-sized pieces with a hammerstone to speed drying

Outils nécessaires :

HammerstoneHammerstone
10

Lay Out to Dry

Spread the ore pieces on flat stones in direct sunlight and leave for 2-3 days to air-dry

Step 10 - Image 1
11

Turn Daily

Turn the pieces once daily to ensure even drying on all sides

12

Build Roasting Fire

Build a small open fire and let it burn down to a strong bed of coals

Matériaux pour cette étape :

FirewoodFirewood1 botte
13

Roast the Ore

Place dried ore chunks around the fire perimeter and roast for 1-2 hours to drive off remaining moisture

14

Listen for Cracking

Listen for cracking and popping sounds — this indicates chemically-bound water escaping from the ore structure

15

Cool Completely

Remove roasted ore from the fire area and allow it to cool completely before handling

16

Crush Roasted Ore

Crush the roasted ore into walnut-sized fragments with a hammerstone on a flat stone anvil

Step 16 - Image 1

Outils nécessaires :

HammerstoneHammerstone
17

Sift the Fragments

Sift the crushed ore through a coarse basket to separate fine powder from the usable fragments

Outils nécessaires :

ContainerContainer
18

Store for Smelting

Store the processed ore in a dry container — it is now ready to charge into a bloomery furnace for smelting

Outils nécessaires :

ContainerContainer

Matériaux

2

Outils requis

4
