Silicone (Rochow Direct Process)

Silicones - chains of silicon and oxygen carrying methyl groups - were known from Frederic Kipping's laboratory work, but could only be made a few grams at a time. In 1940 Eugene Rochow at General Electric found a one-step route: pass methyl chloride over hot silicon with copper, and methylchlorosilanes come straight off. Richard Müller found the same reaction independently in Germany, which is why it is also called the Müller-Rochow process. It is how silicones are still made. **US 2,380,995**, "Preparation of organosilicon halides", Rochow, assigned to General Electric, granted 7. August 1945, claims "effecting reaction between silicon and a hydrocarbon halide" with a copper catalyst at 200–500 °C. **Methyl chloride and chlorosilanes are toxic and stay in the plant.** You use the product: a two-part silicone mould of glass marbles, then cast hot wax in it, again and again.
शुरुआती
4 hours plus two cures

निर्देश

1

Build the box

Cut foam board and hot-glue an open box 60 x 40 mm inside, 50 mm tall. Seal every inside seam with a bead of glue - silicone finds any gap.

इस चरण के लिए सामग्री:

प्रतिरूप निर्माण का झागदार गत्ताप्रतिरूप निर्माण का झागदार गत्ता1 शीट

आवश्यक उपकरण:

शिल्प चाकूशिल्प चाकू
गरम गोंद की बंदूकगरम गोंद की बंदूक
इस्पात का पैमानाइस्पात का पैमाना
2

Clay bed and keys

Press sulphur-free modelling clay 20 mm deep into the box. Push two 16 mm marbles exactly halfway in, 20 mm apart. Press four dimples in the clay with a pencil end: these are the registration keys.

इस चरण के लिए सामग्री:

गढ़ने की मिट्टीगढ़ने की मिट्टी150 ग्रा
काँच की गोलियाँकाँच की गोलियाँ2 टुकड़े

आवश्यक उपकरण:

डिजिटल वर्नियर कैलिपर, 6 इंचडिजिटल वर्नियर कैलिपर, 6 इंच
3

Weigh and mix

Weigh part A and part B at the kit's stated ratio into a mixing cup (the notebook gives the mass). Stir 3 minutes, scraping sides and bottom.

इस चरण के लिए सामग्री:

सिलिकॉन साँचा बनाने की किटसिलिकॉन साँचा बनाने की किट1 किट

आवश्यक उपकरण:

परिशुद्ध डिजिटल तराज़ूपरिशुद्ध डिजिटल तराज़ू
अंशांकित मिलाने के प्यालेअंशांकित मिलाने के प्याले
हिलाने वाली छड़हिलाने वाली छड़
4

First pour

Pour in a thin stream from 30 cm into one corner, never onto the marbles, until 6 mm above them. Cure for the kit's time.

आवश्यक उपकरण:

अंशांकित मिलाने के प्यालेअंशांकित मिलाने के प्याले
5

Flip and release

Flip the box, peel away all clay and leave the marbles in the silicone. Brush a thin coat of petroleum jelly over the silicone face - silicone bonds to silicone.

इस चरण के लिए सामग्री:

वैसलीनवैसलीन5 ग्रा
6

Second pour

Mix a second batch the same way and pour 6 mm above the marbles. Cure again.

इस चरण के लिए सामग्री:

सिलिकॉन साँचा बनाने की किटसिलिकॉन साँचा बनाने की किट1 किट

आवश्यक उपकरण:

परिशुद्ध डिजिटल तराज़ूपरिशुद्ध डिजिटल तराज़ू
अंशांकित मिलाने के प्यालेअंशांकित मिलाने के प्याले
7

Open and cut sprues

Tear off the foam board, part the halves and pop out the marbles. With the craft knife cut a 5 mm cone from the top face into each cavity.

आवश्यक उपकरण:

शिल्प चाकूशिल्प चाकू
8

Cast wax

Melt paraffin wax in the double boiler to 75 °C. Band the halves shut, pour through each sprue, cool 30 minutes, open. Count how many casts it survives.

इस चरण के लिए सामग्री:

पैराफिन मोमपैराफिन मोम100 ग्रा
रबर बैंडरबर बैंड1 पैक

आवश्यक उपकरण:

दोहरा पतीलादोहरा पतीला
मिठाई का तापमापीमिठाई का तापमापी
वेल्डिंग के दस्तानेवेल्डिंग के दस्ताने
पारदर्शी सुरक्षा चश्मापारदर्शी सुरक्षा चश्मा
9

Troubleshoot the mould

Work down in order; each question points to one step to redo.

Flow

Loading...
10

Reaction, pour size, siblings

Jupyter नोटबुक लोड हो रही है…
11

History & Context

**What the patent specifies:** silicon reacted with a hydrocarbon halide over copper at 200–500 °C to give organosilicon halides. **Modern build (derived):** a two-part room-temperature-curing mould silicone. Silicone first served in the Second World War as grease and insulation for aircraft ignition systems; today it is sealant, bakeware, medical tubing and every maker's mould rubber. Its limits: it tears easily once nicked, is expensive, and a platinum-cure grade will not set against sulphur, some clays and latex gloves.
