Purifying Water with a Natural Filter — Charcoal, Sand & Gravel
Build a three-layer water filter from charcoal, sand, and gravel. Important: always boil filtered water for 1 minute — filtration alone does not kill all pathogens.
Olùbẹ̀rẹ̀
30-45 minutes
Ìlànà
1
1
Filter Layer Diagram
Filter Layer Diagram
Water flows top to bottom through three layers: charcoal (chemical filtration) → sand (physical filtration) → gravel (structural support). Always boil after filtering.
Flow
Loading...
2
2
Make Charcoal
Make Charcoal
Burn hardwood until fully black. Smother with sand to stop combustion. Cool, then crush to pea-sized pieces. ~2 cups needed.
Àwọn irinṣẹ́ tí a nílò:
Ohun ìdáná
Ọ̀bẹ iṣẹ́3
3
Assemble Filter
Assemble Filter
Container (bark cone, hollow log, or cut bottle). Grass plug at drain. Layer: 5-8cm gravel, 8-10cm sand, 5-8cm charcoal, thin gravel cap on top.
Àpẹrẹ
Cross-section: labeled layers with measurements
Àwọn ohun èlò fún ìgbésẹ̀ yìí:
Ìgbá1 ẹyọ
Ìdì ìtọ́ná1 ìkúnwọ́
Òkúta wẹ́wẹ́2 ife
Iyanrìn Kékeré3 ife
Èédú Fífọ́2 ife4
4
Filter & Boil
Filter & Boil
Pour water slowly. Discard first dark batch (charcoal dust). By third pass, water runs clear. ALWAYS boil 1 minute before drinking.
Àwọn irinṣẹ́ tí a nílò:
Ohun ìdánáÀwọn ohun-èlò
7- 1 ẹyọÀyè
- 1 ìkúnwọ́Àyè
- 2 ifeÀyè
- 3 ifeÀyè
- 2 ifeÀyè
- 1 ìkúnwọ́Àyè
- Àyè
