Skiving: Where Leather Has to Get Thinner to Work

Leather that is the right thickness for a bag body is too thick where it folds, too thick where two layers overlap, and far too thick where four layers meet at a corner. Skiving is shaving it thinner in exactly those places — a long shallow taper, usually on the flesh side, that lets a fold lie flat or two edges meet without a step. It is the operation that separates work that looks homemade from work that does not, and it is entirely a matter of a sharp blade held at a low angle. There is no jig that does it well.
Средний
3 hours

Инструкции

1

The four places it is needed

**A fold.** Leather folded at full thickness makes a fat rounded bend that cracks the grain on the outside. Skiving the flesh side along the fold line, to about half thickness over a band twice the leather's thickness, lets it turn sharply and lie flat. **An overlap or a lap joint.** Two pieces glued face to face double the thickness and leave a visible step. Skive both mating edges to a long taper and the joint finishes at the same thickness as the rest, with no step at all. This is how a belt loop, a bag gusset and a shoe upper are all made. **A turned edge.** Where leather is folded over on itself to give a finished edge — a bag mouth, a strap end, a bookbinding turn-in — the turned part is skived thin so the doubled edge is no thicker than the single one. **A corner where several layers meet.** Skive each layer progressively so the stack never exceeds what the needle and the thread can handle. The general rule: skive wherever the finished piece would otherwise be thicker than it looks like it should be.

Материалы для этого шага:

Кожа растительного дубленияКожа растительного дубления2 штук

Необходимые инструменты:

Сапожный ножСапожный нож
Цифровой штангенциркуль 6 дюймовЦифровой штангенциркуль 6 дюймов
Самовосстанавливающийся мат для резкиСамовосстанавливающийся мат для резки
2

Doing it by hand

**Work on a hard smooth surface** — a marble offcut, a glass slab, a poly board. A soft cutting mat lets the leather sink and the blade digs in. **Blade almost flat.** The angle between the blade and the leather is what sets the taper: a few degrees for a long gentle skive, more for a short one. A blade held steeply does not skive, it cuts a hole. **Push away from you in shallow strokes**, taking a thin shaving each time. Half a dozen light passes beat one heavy one, because a heavy pass wanders and goes through. **Stretch the leather flat with the other hand**, fingers well back from the blade and never in front of it. This is the operation that cuts people, because the blade is travelling away at a low angle and there is nothing to stop it. **Check by feel and by light.** Run a thumb across the skive: it should be a smooth ramp with no ridges. Hold it up to a light and a properly skived edge glows evenly through. **A sharp blade is not optional.** A dull edge tears the fibres rather than severing them and leaves a furry surface that will not glue. Strop between pieces.

Материалы для этого шага:

Кожа растительного дубленияКожа растительного дубления2 штук
Козья кожаКозья кожа1 штука

Необходимые инструменты:

Сапожный ножСапожный нож
МикрометрМикрометр
Цифровой штангенциркуль 6 дюймовЦифровой штангенциркуль 6 дюймов
3

How thin, and how far back

The two numbers that define a skive are its **depth** at the edge and its **length** back from the edge. The ratio between them is the taper. **For a lap joint**, skive each piece to zero at the edge over a length of about **ten times the leather's thickness**. Two 2 mm pieces therefore each get a 20 mm taper, and the finished overlap is 2 mm thick rather than 4 mm. **For a fold**, take it to about **half thickness** over a band about **twice the thickness** wide, centred on the fold line. It should bend easily and still have body. **For a turned edge**, skive to about **a third of thickness** over the width of the turn-in plus a little. **Never skive to nothing where it will be stitched.** A feather edge has no fibres left to hold a thread and tears out. Stop at about a third of the original thickness anywhere a stitch line will run. Measure with a caliper on a test piece before committing. The eye is poor at judging half a millimetre and the difference between 1 mm and 0.5 mm is the difference between a joint that lies flat and one that does not.

Материалы для этого шага:

Кожа растительного дубленияКожа растительного дубления2 штук

Необходимые инструменты:

Цифровой штангенциркуль 6 дюймовЦифровой штангенциркуль 6 дюймов
МикрометрМикрометр
ЛинейкаЛинейка
4

When not to skive, and what to do instead

Skiving removes material, and material is strength. Three cases where it is the wrong answer: **Where the piece carries load.** A strap near a buckle, the shoulder of a bag handle, anything that takes weight. Thinning it there is exactly where it will break. Design the fold somewhere else instead. **Where a stitch line will run.** As above: leave fibres for the thread to hold onto. **Where the leather is already thin.** Below about 2 oz there is nothing to take away. Choose a thinner piece for the part that needs to be thin, or line it instead. The alternatives, in order of how often they are the better answer: **Use a thinner piece there.** Obvious, usually right, and the reason a well-made bag is made of several weights of leather rather than one. **Split the whole piece.** A splitting machine takes a sheet down evenly across its whole area. Leather merchants will split to order, and the result is far more even than hand skiving. **Change the joint.** A butted joint backed with a strip needs no skive at all. A gusset avoids the four-layer corner entirely.

Материалы для этого шага:

Кожа растительного дубленияКожа растительного дубления1 штука
Козья кожаКозья кожа1 штука

Необходимые инструменты:

Цифровой штангенциркуль 6 дюймовЦифровой штангенциркуль 6 дюймов
