Brass Reed Shim Rolled Thin and Left Spring-Hard
Reeds and small springs want thin brass that springs back. Roll brass sheet thinner a little at a time, annealing when it stiffens, and leave the last passes unannealed: cold rolling hardens brass, and that hardness is the spring.
The picture: a corroded brass reed plate from a harmonica of the American Civil War era (US National Park Service).
Trung cấp
Half a day
Hướng dẫn
1
1
Anneal the sheet
Anneal the sheet
Cut a strip from the brass sheet, heat it on fire bricks to a dull red and quench it in water.
Vật liệu cho bước này:
Tấm đồng thau1 cái
Nước5 lítCông cụ cần thiết:
Kéo cắt tôn
Đèn khò propan
Gạch chịu lửa
Kìm rèn
Thùng tôi nước2
2
Roll it down
Roll it down
Pass it through the rolling mill, closing the rolls a little each pass. When it stiffens and starts to crack at the edges, anneal it again.
Công cụ cần thiết:
Máy cán
Thước cặp điện tử 6 inch
Đèn khò propan
Thùng tôi nước
Kính bảo hộ3
3
Finish hard
Finish hard
For the last few passes do not anneal. Roll to the reed thickness, often a few tenths of a millimetre, and check it at several points.
Công cụ cần thiết:
Máy cán
Thước cặp điện tử 6 inch4
4
Clean and cut
Clean and cut
Lift the oxide in vinegar with salt, scrub, rinse and dry. Cut it into reed blanks with snips.
Vật liệu cho bước này:
Giấm0.5 lít
Muối20 gCông cụ cần thiết:
Bát
Bộ bàn chải sắt
Kéo cắt tôn5
5
Pass schedule
Pass schedule
Đang tải sổ tay Jupyter…
