The Two-Fulcrum Nut Cracker: A Pick Kept in the Handle

One cracker cannot suit both a small pecan and a big walnut, and the pick that goes with it is always lost on the table. Herbert Story of Kearney, New Jersey, received US 417,951, dated 24 December 1889, for a combined nut cracker and picker "useful and convenient" and "neat in appearance and at a small cost": the jaws pivot on a variable fulcrum with one place for small nuts and one for larger nuts, and one handle is a tube in which the nut pick is kept, screwed in, until it is wanted. He wrote plainly: "I do not claim, broadly, a combined nut cracker and picker, as such implements, are not new". This rung works out squeeze and handle spread for two fulcrum holes, then builds the cracker from flat bar with a brass-tube handle and cracks pecans and walnuts in each hole.
Àárín
About 3 hours

Ìlànà

1

Squeeze and handle spread

Ń ṣí ìwé Jupyter…
2

A pivot that does the work

The embedded blueprint builds pivoted tongs with a spring by the pivot. Story's cracker gives the pivot two places to go.
3

Read US 417,951

"In said drawings, a a represent the two jaws of a nut-cracker with handles a′ a′, and pivoted at a² to a variable fulcrum b, one portion of said fulcrum b′ being arranged for small nuts and the other portion b² for larger nuts." "When the nut-cracker only is to be employed, the nut-pick is allowed to remain in the handle, secured by the screw f, where it is out of the way and in no manner interferes with the use of the cracker".
4

Build the cracker and crack both sizes

**Bars.** Cut two 20 cm lengths of 20 × 5 mm mild steel flat bar. File a shallow V across the inside face of each near one end: the jaws. Clamp the two bars together and drill two 6.5 mm holes through both, 20 mm and 35 mm from the middle of the jaws. **Pick handle.** Cut 12 cm of 3/8" brass tube and epoxy it along the outside of one handle, open at the end, as the socket for a nut pick. Let it cure. **Pivot.** Bolt the bars through the near hole with an M6 bolt and two nuts locked against each other. **Test.** Crack five pecans and five walnuts; measure the handle spread at the crack with the ruler. Move the bolt to the far hole and do the same. Compare with the notebook and with your own grip. Keep the nut pick in the tube between uses.

Àwọn ohun èlò fún ìgbésẹ̀ yìí:

Ọ̀pá Pẹrẹsẹ Irin Pẹ́lẹ́Ọ̀pá Pẹrẹsẹ Irin Pẹ́lẹ́0.4 mítà
Àkójọ bọ́ọ̀lù onígun mẹ́fàÀkójọ bọ́ọ̀lù onígun mẹ́fà1 ẹyọ
Nọ́ọ̀tì Onígun Mẹ́fàNọ́ọ̀tì Onígun Mẹ́fà2 ẹyọ
Ọ̀pá idẹ tí ìwọ̀n àyíká òde rẹ̀ jẹ́ 9,5 mmỌ̀pá idẹ tí ìwọ̀n àyíká òde rẹ̀ jẹ́ 9,5 mm0.12 mítà
Resini epoxyResini epoxy5 ml
Wọ́lnọ́ọ̀tìWọ́lnọ́ọ̀tì10 ẹyọ
PecanPecan10 ẹyọ

Àwọn irinṣẹ́ tí a nílò:

Ayùn IrinAyùn Irin
Ìdìmú TábìlìÌdìmú Tábìlì
Àwọn Ìfá (Ìfá Ọwọ́)Àwọn Ìfá (Ìfá Ọwọ́)
Ẹ̀rọ Ìlùkòkò AláìlókùnẸ̀rọ Ìlùkòkò Aláìlókùn
Àkójọ Orí ÌlùkòkòÀkójọ Orí Ìlùkòkò
Kọ́kọ́rọ́ tí a lè ṣàtúnṣeKọ́kọ́rọ́ tí a lè ṣàtúnṣe
Ìdíwọ̀nÌdíwọ̀n
Òṣùwọ̀n Kálípà Díjítà Ìnṣì 6Òṣùwọ̀n Kálípà Díjítà Ìnṣì 6
Ohun èlò ìyọ inú èso líleOhun èlò ìyọ inú èso líle
Gílásì Ààbò Tí Ó Mọ́Gílásì Ààbò Tí Ó Mọ́
5

A cracker that will not open wide enough or slips

Two-fulcrum nut cracker troubleshooting.

Flow

Loading...
6

History and honest limits

**Herbert Story** of Kearney, Hudson County, New Jersey, signed US 417,951 on 15 September 1888, filed it on 12 November 1888, and received it dated 24 December 1889. His solid handle carried a projection to match the socket on the other, "thus giving to the handle a uniform finish", and the pick screwed into the tubular handle. **Honest limits.** Two drilled holes stand in for Story's fulcrum piece, and a push-fit brass tube for his threaded socket. The notebook assumes handles and jaws close together; its squeeze, lengths and nut sizes are examples. Your spreads and cracks are the result.
